Mini-Z Body Compatibility: MR-03, MR-04, MA-020

Buying a Mini-Z body without checking compatibility is how you end up with a gorgeous licensed shell that won’t fit your chassis. This guide covers the 3 things that matter most:

• Wheelbase (mm)
• Body width
• Wheel offset (mm)

If you want the fast answer: match the wheelbase first, then use offset to get the wheels centered in the arches. Still deciding which chassis to buy? The MR-03 vs MR-04 comparison covers the platform differences that matter before you pick a body.

If you already know your chassis and want to start shopping, skip to the Starting Point Picks section at the bottom.

Wheelbase (Compatibility Chart)

Wheelbase is the distance between front and rear axles. Mini‑Z bodies are designed around a specific wheelbase setting, so this is the first thing to match.

Wheelbase	Kyosho code	Example bodies in Kyosho’s listings
86mm	S	Lancia Stratos (legacy)
90mm	M	Ferrari F40, Mazda RX-7 FD3S, Porsche 911 GT3 RSR (legacy)
94mm	L	ARTA / Takata Dome NSX 2007 (legacy)
98mm	LL	Raybrig NSX Concept-GT 2014, McLaren 12C GT3 2013, GT-R SUPER GT 2008 (legacy), Ferrari Enzo (legacy)
102mm	3L	Group C prototypes such as the Porsche 962C and Mazda 787B (legacy)
106mm	4L	Longest setting on the MR-03

The MR-03 chassis spans 86mm to 106mm. The MA-020 covers 90mm to 98mm, so the 102mm and 106mm bodies need an MR-03. Codes come from Kyosho’s MR-03 Technical Guide and the MA-020 page. The “legacy” bodies come from Kyosho’s May 2010 MR-03 parts list. Some may be discontinued or reissued, so confirm the wheelbase on the listing for the exact body you buy.

Tip: if a body lists multiple wheelbases, it usually means the chassis can be configured to match (different motor mounts / T-plates / rear pod positions depending on platform).

Body Width and Wheel Offset

Body width is the overall width of the shell. Wheel offset is how far the wheel mounting face moves the wheel inboard/outboard relative to the hub.

If compatibility feels confusing, it’s usually offset.

• Too little offset → wheels sit tucked in, don’t fill the arches.
• Too much offset → tires rub the body, steering binds, or the shell won’t sit down.

Kyosho lists a specific offset for each body, anywhere from 0.0 up to +3.5 at the front, and front and rear often differ (the McLaren 12C GT3 is +1.5 front / +2.5 rear, for example). Match the body’s spec with your wheels. For a full breakdown of how offset numbers work and affect handling, see the Wheel Offset and Width Guide.

Practical rule: wheelbase makes it fit; offset makes it look right.

If you’re sorting out offset on an MR-03 setup, this Kyosho MR-03 narrow wheel set is a 2.5mm offset, which suits a body that lists +2.5 front. It’s inexpensive enough to grab a couple of different offset sizes while you dial things in.

→ Kyosho 2.5mm Offset Narrow CE28N Mini-Z Wheel Set on Amazon

MR-03 vs MA-020 (RWD vs AWD)

• MR‑03 (RWD): the default for most “race” setups; huge body support. See the MR-03 Platform Guide for full setup and body selection details.
• MA‑020 (AWD): shares many bodies with MR‑03 (Kyosho says most MINI-Z 01/015 body styles fit), but the drivetrain/steering layout can make some shells a tighter fit. See the MA-020 Platform Guide for AWD-specific body notes.

In general, if the body is listed for both platforms, you’re good. Just make sure you’re matching the wheelbase and offset, and remember the MA-020 tops out at 98mm. See the MR-04 Platform Guide for MR-04 specifics.

The Nissan GT-R and Porsche 911 GT3 are the two starting bodies picked below. Wheelbase is set per body, not per model name. In Kyosho’s own listings the GT-R SUPER GT 2008 is 98mm and the 911 GT3 RSR is 90mm (both legacy, from the 2010 parts list), so read the wheelbase on the exact listing before you buy.

Body Choice and Running Surface

Body selection does not happen in isolation from surface. On high-grip RCP foam, wider bodies with more aggressive offset increase the risk of traction rolling, where the car tips over mid-corner because the outside tire is generating more lateral grip than the chassis can absorb. Narrower bodies with tighter offset reduce that risk. On carpet or hard floors, the same offset that causes traction rolling on RCP may work perfectly fine because the grip level is lower.

This matters when you are choosing between two bodies that both technically fit your chassis: consider where you race. If you run RCP, stay conservative on front offset and prefer Low Height body styles where available. If your tire compound and body choice are combining to cause traction rolling, the Mini-Z Tire Guide covers how to adjust your compound setup to restore balance before you swap bodies. Sometimes the fix is compound, not the shell.

Starting Point Picks {#starting-point-picks}

If you’re newer to Mini-Z and want to skip the research spiral, here are three shells to start from. Wheelbase varies by body, so check each listing against the table above before you buy.

Kyosho Mini-Z licensed body shells run $25-55 on Amazon, generally cheaper than you’d expect for a 1/27 scale licensed replica. The Ferrari pick below is the exception, it is a third-party shell, not a Kyosho license, so price and fit assumptions from the rest of this list do not carry over to it automatically.

Nissan GT-R R35 Body Shell (MR-03 / MA-020) A common first body. Kyosho’s GT-R SUPER GT 2008 is 98mm with +2.0 / +2.0 offset, but I could not tie this listing to that exact Kyosho item, so confirm the wheelbase and offset on the product page before you buy.

→ Kyosho Mini-Z GT-R R35 Body on Amazon

Porsche 911 GT3 Body Shell (MR-03 / MA-020) Kyosho’s 911 GT3 RSR is a 90mm body with +0.5 front / 0.0 rear offset (legacy, 2010 parts list). This listing is a different Kyosho item that I did not spec-check, so confirm wheelbase and offset on the product page.

→ Kyosho Mini-Z Porsche 911 Body on Amazon

Ferrari 488 GT3 Body Shell (MR-03), third-party, not Kyosho OEM Unlike the two bodies above, Kyosho does not manufacture this shell. The 488 GT3 on the market is a third-party shell from GL Racing, built to bolt to Kyosho Mini-Z chassis but sold and licensed independently of Kyosho. I have not verified its wheelbase or offset against any Kyosho spec, so get both from the seller before you order, and do not expect Kyosho-brand packaging, decals, or pricing.

Kyosho MR-03 Narrow Wheel Offset Set If you need to sort out offset to match a body, this set is 2.5mm. Pick the offset your body’s listing calls for, since front and rear values differ from body to body.

→ Kyosho 2.5mm Offset Narrow CE28N Mini-Z Wheel Set on Amazon

---

FAQ (Common Compatibility Questions)

What are the most important numbers to check?

Wheelbase first, then front/rear offset. Width matters, but offset is usually what makes a shell rub or look wrong.

Can I “make” a body fit a different wheelbase?

Sometimes, but it’s rarely worth it. If you’re off by a few mm, the wheels won’t center in the arches and it will look (and often drive) wrong.

Why does my body rub when turning?

Usually front offset is too aggressive or the tire is too wide/tall for the shell. Try reducing front offset (or a narrower tire) first.

Do front and rear offsets need to match?

Not always. Many bodies want different front vs rear offsets to center the wheels properly.

Is “offset” the same thing as track width?

Offset affects track width, but they’re not identical. Track width is the final wheel-to-wheel measurement; offset is one of the main inputs.
